DSC02665 |
Used in Electrical Consumer Goods;
Double-sided
Material / Thickness : FR-4/1.2mm
Board Size :
140mm*159mm
Min. Trace Width / Space : 6mil/6mil
Min Hole Size
: 0.4mm
Finish : Gold Plating
File Format : Gerber |
DSC02647 |
Used in Electrical Equipment; Double-sided
Material /
Thickness: FR-4/1.6mm (Copper thickness: 2oz)
Board Size :
153mm*184mm
Min. Trace Width / Space : 8mil/8mil
Min. Hole
Diameter : 0.5mm
Finish : Chemical Gold Plating
File Format:
Gerber |
DSC02637 |
Computer Mother-board; 4 layers
Material / Thickness
: FR-4/1.6mm
Board Size : 294mm*200mm
Min. Trace Width / Space
: 5mil/5mil
Min. Hole Diameter : 0.3mm
Finish : HAL
File
Format : Gerber |
DSC02639 |
Computer Mother-board; 4 layers
Material / Thickness
: FR-4/1.6mm
Board Size : 294mm*215mm
Min. Trace Width / Space
: 5mil/5mil
Min. Hole Diameter : 0.3mm
Finish : HAL
File
Format : Gerber |
DSC02656 |
Used in telecommunication Products; 6 layers
Material
/ Thickness : FR-4/1.2mm
Board Size : 126mm*141mm
Min. Trace
Width / Spac : 4mil/4mil
Min. Hole Diameter : 0.25mm
Finish :
Chemical Gold Plating
File Format : Gerber |
DSC02660 |
Used in telecommunication Products; 8 layers
Material
/ Thickness : FR-4/1.2mm
Board Size : 94mm*188mm
Min. Trace
Width / Space : 4mil/4mil
Min. Hole Diameter : 0.15mm
Finish:
Chemical Gold Plating
File Format :
Gerber |
